Product Overview
The SF235A-E092B3-F2 is a high-efficiency Ec dual_inet centrifugal fan built for demanding industrial ventilation and air-handling applications. Its EC motor delivers precise, energy-saving speed control while the forward-curved impeller keeps operation quiet.
- Compact industrial housing (IP42)
- Long-life NSK ball bearings
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | SF235A-E092B3-F2 |
| Motor Type | EC |
| Airflow | 1650 m³/h |
| Max Static Pressure | 880 Pa |
| Voltage | 110-230 V AC |
| Power | 240 W |
| Current | 1.5 A |
| Speed | 750 r/min |
| Noise | 62 dB(A) |
| Protection Class | IP42 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | Galvanised sheet steel |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 0-6.5V |
Applications
For general ventilation and air handling units requiring high airflow with energy-efficient electronically commutated operation, the SF235A-E092B3-F2 (EC, 110-230 V AC, 1650 m³/h, 240 W) delivers reliable centrifugal performance across a wide input voltage range. In commercial HVAC supply or exhaust systems, the SF235A-E092B3-F2 (EC, 110-230 V AC, 1650 m³/h, 240 W) provides consistent air movement with low power consumption thanks to its EC motor design. For cleanroom or process cooling applications needing stable medium-pressure airflow, the SF235A-E092B3-F2 (EC, 110-230 V AC, 1650 m³/h, 240 W) is suitable for continuous duty where variable speed control and 110-230 V AC compatibility are required.
Ordering Information
| MOQ (Min. Order Qty) | 96 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Performance Curves
Dimensions
Special Remarks
Housing and impeller material: galvanized steel plate + electrophoretic black.
