22580 DC Axial Fan — 1100 m³/h

DC IP54
AG200B-D092A6-03 Axial Fan — 1100 m³/h at 500 Pa
🔍

Product Overview

AG200B-D092A6-03 is a DC axial fan with a 24 Vdc input, delivering 1100 m³/h at up to 500 Pa, 120 W, 3400 r/min, 67 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 45–125 FOB Nansha, MOQ 360 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

AG200B-D092A6-03 belongs to the AG Axial- Flange range: a DC centrifugal fan rated 24 V DC, 1100 m³/h at up to 500 Pa, 3400 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 67 dB(A).

Duty point: 1100 m³/h at 500 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AG200B-D092A6-03
Motor Type DC
Airflow 1100 m³/h
Max Static Pressure 500 Pa
Voltage 24 V DC
Power 120 W
Current 5 A
Speed 3400 r/min
Noise 67 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material Galvanized steel
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 360 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$45–125
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

04008001200160020000100200300400500 Airflow (m³/h) Static pressure (Pa) 1100 m³/h 500 Pa

Dimensions (No.3)

AG200B-D092A6-03 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: Galvanized steel plate+powder coating;Flange material:aluminum alloy die casting

Applications

Flanged axial fans (280×280 frame) that bolt directly onto ducts, spigots and cabinet cut-outs — sealed connection, no recirculation losses. 1,100–1,950 m³/h at 300–500 Pa for cabinet ventilation and heat-exchanger duty. DC (24 V / 310 V) and EC (230 V AC) versions with 0-10V/PWM.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Axial fan:AG200B-D092A6-03 Product dataSheets
