EC28080 Axial Fan — 1850 m³/h

EC IP44
AG250C-E072B3-03 Axial Fan — 1850 m³/h at 300 Pa
🔍

Product Overview

AG250C-E072B3-03 is an EC axial fan with a 230 Vac input, delivering 1850 m³/h at up to 300 Pa, 120 W, 2700 r/min, 68 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 45–125 FOB Nansha, MOQ 360 pcs, 25–30 days.

  • Compact industrial housing (IP44)
  • Long-life NSK ball bearings

Selection notes

AG250C-E072B3-03 belongs to the AG Axial- Flange range: a EC centrifugal fan rated 230 V AC, 1850 m³/h at up to 300 Pa, 2700 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 68 dB(A).

Duty point: 1850 m³/h at 300 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AG250C-E072B3-03
Motor Type EC
Airflow 1850 m³/h
Max Static Pressure 300 Pa
Voltage 230 V AC
Power 120 W
Current 0.52 A
Speed 2700 r/min
Noise 68 dB(A)
Protection Class IP44
Working Temperature -25 °C ~ +60 °C
Impeller Material PA66+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 360 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$45–125
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

04008001200160020000100200300400500 Airflow (m³/h) Static pressure (Pa) 1850 m³/h 300 Pa

Dimensions (No.1)

AG250C-E072B3-03 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Impeller+Flange material options: Pa66

Applications

Flanged axial fans (280×280 frame) that bolt directly onto ducts, spigots and cabinet cut-outs — sealed connection, no recirculation losses. 1,100–1,950 m³/h at 300–500 Pa for cabinet ventilation and heat-exchanger duty. DC (24 V / 310 V) and EC (230 V AC) versions with 0-10V/PWM.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Axial fan:AG250C-E072B3-03 Product dataSheets

Frequently Asked Questions

What are the installation advantages of an EC 280×280×80 mm axial fan with flange?

**EC axial fan, 280×280×80 mm, with flange, 230V, and 0-10V/PWM speed control**, belonging to the category of **high-airflow, slim-profile, intelligently controllable** industrial-grade cooling and ventilation fans. The flange structure facilitates mounting through openings in enclosures or wall panels. The 80mm slim depth greatly saves internal equipment space, while the EC motor combined with 0-10V/PWM speed control enables on-demand air supply and low energy consumption. ### Installation Advantages Summary - **Flange:** Provides robust four-corner/perimeter bolt fixing with high fit accuracy, easy sealing, and leakage prevention. - **80mm Ultra-Slim Depth:** Suitable for "flat" equipment structures with stringent axial space requirements. - **0-10V / PWM:** The core of intelligent control, capable of directly interfacing with sensors, PLCs, or smart main control boards to achieve stepless speed regulation, soft start, and fault feedback.

Flange or guard-ring mounting — which AG variant do I need?

The flange version bolts into a cut-out and carries its weight through the flange plate — the natural choice for wall and partition openings, condenser casings and duct transitions. The guard-ring build (AS series) is for open discharge: a ring with integrated finger protection, free-blowing over coils or in windows. Decide by what surrounds the fan: a structure that can take a flange gives the stiffest, quietest mount; free air wants a guard.

How much static pressure can an axial fan realistically deliver?

This one is rated to 300 Pa — a typical ceiling for a well-made axial of this class before efficiency and noise degrade badly. That covers coils, louvres and short ducts, the native duty of axial fans. Beyond roughly 300-500 Pa the honest answer is a centrifugal: pushing an axial into high pressure puts it in stall-prone territory with a harsh tonal signature. Pick the fan type from the system resistance first, then the model.
