Centrifugal Fan

EC120 Single inlet Centrifugal Fan — 300 m³/h

EC IP44
DG120A-E072A1-01 Centrifugal Fan — 300 m³/h at 405 Pa
🔍

Product Overview

DG120A-E072A1-01 is an EC centrifugal fan with a 115 Vac input, delivering 300 m³/h at up to 405 Pa, 50W, 2150 r/min, 58 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 28–65 FOB Nansha, MOQ 192 pcs, 25–30 days.

  • Compact industrial housing (IP44)
  • Long-life NSK ball bearings

Selection notes

DG120A-E072A1-01 belongs to the DG120 range: a EC centrifugal fan rated 115 V AC, 300 m³/h at up to 405 Pa, 2150 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 58 dB(A).

Duty point: 300 m³/h at 405 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model DG120A-E072A1-01
Motor Type EC
Airflow 300 m³/h
Max Static Pressure 405 Pa
Voltage 115 V AC
Power 50W
Current 0.43 A
Speed 2150 r/min
Noise 58 dB(A)
Protection Class IP44
Working Temperature -25 °C ~ +60 °C
Impeller Material PP+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 192 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$28–65
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

01002003004005000100200300400500 Airflow (m³/h) Static pressure (Pa) 300 m³/h 405 Pa

Dimensions (No.1)

DG120A-E072A1-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: Galvanised sheet steel

Applications

Single-inlet 120 mm EC centrifugal blowers, 300–380 m³/h at 405–605 Pa — high pressure from a palm-sized wheel, and quiet at 56–61 dB(A). Duty: medical devices, laser cabinets, kiosks and dense electronics racks. 115/230 V AC, 0-10V/PWM, IP44.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:DG120A-E072A1-01 Product dataSheets

Frequently Asked Questions

Single-inlet or dual-inlet centrifugal — which fits a compact chassis?

A single-inlet wheel draws air from one face only, so the blower mounts flush against a panel and the discharge ducts away in one plane; a dual-inlet wheel of the same diameter moves roughly twice the airflow but needs both faces clear. The DG120 trades width for pressure: 300 m³/h against 405 Pa from a 120 mm one-sided wheel. In shallow cabinets — kiosk purge, laser enclosures, wall-hung fresh-air units — that pressure-per-depth is what makes the duct work; where both sides are open and airflow rules, choose dual-inlet instead.

How quiet can it run in noise-sensitive equipment?

Full-speed rating is 58 dB(A) (series span 56–61). As an EC motor with 0-10V/PWM or 3-speed taps, speed can be trimmed to the true duty: at about 70% speed you keep roughly 70% of airflow, shed 7–8 dB(A) and draw about a third of the power. In a bathroom extractor or bedroom fresh-air unit that is the difference between audible and unnoticed. Keep a minimum-speed floor near 30% so the motor keeps its cooling airflow and the impeller stays in its stable range.

How does a 120 mm wheel reach 405–605 Pa?

Static pressure follows tip speed and blade work, not wheel diameter alone. At 2,150 r/min this 120 mm wheel runs about 13.5 m/s tip speed and builds 405 Pa; the faster DG120B (2,600 r/min) reaches 605 Pa from the same diameter. A larger wheel would buy airflow and quieter running rather than pressure — if the duct is long and narrow for its flow, a small fast wheel is the honest route to 400 Pa-class duty.
