Product Overview
DG120C-E072A1-01 is an EC centrifugal fan with a 115 Vac input, delivering 300 m³/h at up to 405 Pa, 50W, 2150 r/min, 56 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 28–65 FOB Nansha, MOQ 192 pcs, 25–30 days.
- Compact industrial housing (IP44)
- Long-life NSK ball bearings
Selection notes
DG120C-E072A1-01 belongs to the DG120 range: a EC centrifugal fan rated 115 V AC, 300 m³/h at up to 405 Pa, 2150 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 56 dB(A).
Duty point: 300 m³/h at 405 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | DG120C-E072A1-01 |
| Motor Type | EC |
| Airflow | 300 m³/h |
| Max Static Pressure | 405 Pa |
| Voltage | 115 V AC |
| Power | 50W |
| Current | 0.43 A |
| Speed | 2150 r/min |
| Noise | 56 dB(A) |
| Protection Class | IP44 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | PP+GF |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 192 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$28–65 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.2)
Special Remarks
Housing & Impeller material made by: PP
Applications
Single-inlet 120 mm EC centrifugal blowers, 300–380 m³/h at 405–605 Pa — high pressure from a palm-sized wheel, and quiet at 56–61 dB(A). Duty: medical devices, laser cabinets, kiosks and dense electronics racks. 115/230 V AC, 0-10V/PWM, IP44.
