Centrifugal Fan

DC200 Single inlet Centrifugal Fan — 1050 m³/h

DC IP54

Product Overview

DG200D-D092B0-01 is a DC centrifugal fan with a 310 Vdc input, delivering 1050 m³/h at up to 305 Pa, 120 W, 950 r/min, 59 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 55–180 FOB Nansha, MOQ 96 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

DG200D-D092B0-01 belongs to the DG200 range: a DC centrifugal fan rated 310 V DC, 1050 m³/h at up to 305 Pa, 950 r/min. Speed is set through 0-10V/PWM, 0-5V; the datasheet sound pressure is 59 dB(A).

Duty point: 1050 m³/h at 305 Pa. Because speed can be trimmed through 0-10V/PWM, 0-5V, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model DG200D-D092B0-01
Motor Type DC
Airflow 1050 m³/h
Max Static Pressure 305 Pa
Voltage 310 V DC
Power 120 W
Current 0.39 A
Speed 950 r/min
Noise 59 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +50 °C
Impeller Material PP+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 0-5V

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 96 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$55–180
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

04008001200160020000100200300400500 Airflow (m³/h) Static pressure (Pa) 1050 m³/h 305 Pa

Dimensions (No.2)

DG200D-D092B0-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: galvanized sheet or PP

Applications

200 mm single-inlet blowers, 1,050–1,300 m³/h at 305–500 Pa, in EC (115/230 V AC) and 310 V DC builds. The DC version taps the rectified mains bus of inverter appliances — heat pumps, dehumidifiers — with no extra power supply. IP54.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Centrifugal fan:DG200D-D092B0-01 Product dataSheets

Frequently Asked Questions

DC 310V single-inlet centrifugal blower, 120W. What are the selection advantages of this fan specification?

### Fan Selection Advantages of DC310V Power Supply Specifications: - **DC310V Bus Power Supply:** Directly driven by AC 220V after rectifier bridge and capacitor filtering, eliminating the need for a high-power step-down transformer, resulting in high overall system efficiency and low heat generation. - **Single-Inlet Scroll Housing Design:** Compared to dual-inlet fans, the single-inlet structure provides a more concentrated air outlet, generating higher static pressure, making it ideal for high-resistance equipment with **filters, ducts, heat sink fins, or narrow air channels**. - **Intelligent Speed Control and Regulation:** Generally supports stepless speed regulation via PWM or 0-5/10V signals, enabling real-time speed adjustment based on internal temperature or pressure sensor feedback for energy-saving and low-noise operation.
