Product Overview
AS960A-E150B3-01 is an EC axial fan with a 380–480 Vac input, delivering 29000 m³/h at up to 300 Pa, 3200 W, 915 r/min, 75 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 300–700 FOB Nansha, MOQ 70 pcs, 25–30 days.
- Compact industrial housing (IP55)
- Long-life ball bearings
With guard-ring or fan-ring mounting, AS axial fans are also specified for cooling towers and dry coolers, where high airflow at low static pressure and weather-resistant construction matter most.
Selection notes
AS960A-E150B3-01 belongs to the AS Axial-Fan Integrated Guard Ring range: a EC centrifugal fan rated 380-480 V AC, 29000 m³/h at up to 300 Pa, 915 r/min. Speed is set through 0-10V/PWM, Modbus RTU(RS485); the datasheet sound pressure is 75 dB(A).
Duty point: 29000 m³/h at 300 Pa. Because speed can be trimmed through 0-10V/PWM, Modbus RTU(RS485), the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Axial Fan |
|---|---|
| Model | AS960A-E150B3-01 |
| Motor Type | EC |
| Airflow | 29000 m³/h |
| Max Static Pressure | 300 Pa |
| Voltage | 380-480 V AC |
| Power | 3200 W |
| Current | 8.0 A |
| Speed | 915 r/min |
| Noise | 75 dB(A) |
| Protection Class | IP55 |
| Working Temperature | -40 °C ~ +65 °C |
| Impeller Material | PA6+GF30% |
| Bearing Type | ball bearing |
| Speed Control | 0-10V/PWM, Modbus RTU(RS485) |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 70 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$300–700 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions
Special Remarks
Wall ring: Sheet,Electrophoresis and coated in Black matt plastic; Guard grille:Stell,Electrophoresis and coated in Black matt plastic;
Applications
Large EC axial fans (760–960 mm impeller, 380–480 V AC) with wall ring and guard for free-cooling walls, large AHUs and industrial air exchange. 16,500–29,000 m³/h per fan; 0-10V/PWM and Modbus RTU for plant integration. -40 °C to +65 °C operating window.
