EC175 Backward-Curved Centrifugal Fan — 680 m³/h

EC IP54
BC175B-E072D1-01 Centrifugal Fan — 680 m³/h at 615 Pa
🔍

Product Overview

BC175B-E072D1-01 is an EC centrifugal fan with a 115 Vac input, delivering 680 m³/h at up to 615 Pa, 90 W, 4000 r/min, 71 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 30–70 FOB Nansha, MOQ 432 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Mounted on a support bracket without a volute, the BC impeller also works as a plug fan (plenum fan) inside AHU sections and cabinet plenums, where the casing is built by the unit manufacturer.

Selection notes

BC175B-E072D1-01 belongs to the BC175 range: a EC centrifugal fan rated 115 V AC, 680 m³/h at up to 615 Pa, 4000 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 71 dB(A).

Duty point: 680 m³/h at 615 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC175B-E072D1-01
Motor Type EC
Airflow 680 m³/h
Max Static Pressure 615 Pa
Voltage 115 V AC
Power 90 W
Current 0.78 A
Speed 4000 r/min
Noise 71 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 432 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$30–70
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

0200400600800100002004006008001000 Airflow (m³/h) Static pressure (Pa) 680 m³/h 615 Pa

Dimensions (No.2)

BC175B-E072D1-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

Backward-curved EC/DC centrifugal fans, 540–780 m³/h at up to 770 Pa, with a non-overloading power curve for continuous duty in AHUs, FFU/cleanroom modules, heat pumps and power-electronics cooling. 48 V DC versions run straight off telecom DC plants; IP54, -25 °C to +60 °C.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:BC175B-E072D1-01 Product dataSheets
