DC175 Backward-Curved Centrifugal Fan — 540 m³/h

DC IP54
BC175B-D061B8-01 Centrifugal Fan — 540 m³/h at 360 Pa
🔍

Product Overview

BC175B-D061B8-01 is a DC centrifugal fan with a 48 Vdc input, delivering 540 m³/h at up to 360 Pa, 40 W, 3100 r/min, 64±2 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 30–70 FOB Nansha, MOQ 432 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Mounted on a support bracket without a volute, the BC impeller also works as a plug fan (plenum fan) inside AHU sections and cabinet plenums, where the casing is built by the unit manufacturer.

Selection notes

BC175B-D061B8-01 belongs to the BC175 range: a DC centrifugal fan rated 48 V DC, 540 m³/h at up to 360 Pa, 3100 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 64±2 dB(A).

Duty point: 540 m³/h at 360 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC175B-D061B8-01
Motor Type DC
Airflow 540 m³/h
Max Static Pressure 360 Pa
Voltage 48 V DC
Power 40 W
Current 0.9±7% A
Speed 3100 r/min
Noise 64±2 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 432 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$30–70
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

020040060080010000100200300400500 Airflow (m³/h) Static pressure (Pa) 540 m³/h 360 Pa

Dimensions (No.3)

BC175B-D061B8-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

Backward-curved EC/DC centrifugal fans, 540–780 m³/h at up to 770 Pa, with a non-overloading power curve for continuous duty in AHUs, FFU/cleanroom modules, heat pumps and power-electronics cooling. 48 V DC versions run straight off telecom DC plants; IP54, -25 °C to +60 °C.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Centrifugal fan:BC175B-D061B8-01 Product dataSheets

Frequently Asked Questions

What does non-overloading mean on a backward-curved wheel — and why should I care?

On a forward-curved fan, power keeps climbing as airflow increases, so a burst duct or a missing filter can push the motor past its rating. A backward-curved wheel like the BC175’s reaches a power peak and then levels off: even if system resistance collapses, the airflow itself cannot overload the motor. That removes a failure mode you would otherwise cover with oversized protection.

As filters load up, how do I hold airflow constant over the service interval?

Two practical routes: on EC models, close the loop — a differential-pressure sensor across the filter trims the 0-10V command upward as resistance grows. Or size statically: select against the filter’s final (loaded) resistance, typically about twice the clean value, so the BC175’s 770 Pa ceiling covers the whole service life. Either way the fan stays near its efficiency island instead of slowly starving the process.

When does a 48 V DC fan beat a 230 V AC one?

Whenever the site already speaks DC. Telecom shelters run −48 V plants; this fan (540 m³/h, 360 Pa) hangs straight on that bus with no inverter, and ventilation survives a mains failure because the battery string carries it. The same logic applies to solar off-grid cabins and 48 V racks: fewer conversion stages, less to fail.
