Centrifugal Fan

AC220 Backward-Curved Centrifugal Fan — 920 m³/h

AC IP54
BC220A-A092C1-02 Centrifugal Fan — 920 m³/h at 590 Pa
🔍

Product Overview

BC220A-A092C1-02 is an AC centrifugal fan with a 115 Vac input, delivering 920 m³/h at up to 590 Pa, 105 W, 2550 r/min, 71±2 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 39–95 FOB Nansha, MOQ 280 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC220A-A092C1-02 belongs to the BC220 range: a AC centrifugal fan rated 115 VAC, 920 m³/h at up to 590 Pa, 2550 r/min. Speed is set through 3-speed; the datasheet sound pressure is 71±2 dB(A).

Duty point: 920 m³/h at 590 Pa. Because speed can be trimmed through 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC220A-A092C1-02
Motor Type AC
Airflow 920 m³/h
Max Static Pressure 590 Pa
Voltage 115 VAC
Power 105 W
Current 0.91 A
Speed 2550 r/min
Noise 71±2 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 280 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$39–95
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

0200400600800100002004006008001000 Airflow (m³/h) Static pressure (Pa) 920 m³/h 590 Pa

Dimensions (No.4)

BC220A-A092C1-02 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

220 mm backward-curved centrifugal fans covering 920–1,180 m³/h at 590–815 Pa — pressure for long duct runs, HEPA stages and ERV cores. One frame, three motor schemes: AC fixed-speed, DC (24 V wide-range, 115 V) and EC (0-10V/PWM). IP54.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · AC·Centrifugal fan:BC220A-A092C1-02 Product dataSheets

Frequently Asked Questions

The BC220 comes in AC, DC and EC — how do I pick one?

AC: fixed-speed or 3-speed duty where nothing modulates and cost rules. DC (24 V wide-range, 115 V): battery or vehicle power. EC (0-10V/PWM): anything that modulates. All three share the 220 mm frame and mounting, so you can prototype with one motor technology and production-order another without redesigning the chassis.

What kind of duct system actually needs 590–815 Pa?

Pressure budgets add up fast: a HEPA terminal alone eats 250–400 Pa at face velocity, an ERV core 100–200 Pa, and every meter of duct and each bend adds its share. Total a filtration stage, a recovery core and a 10 m run, and 600 Pa is gone. The BC220’s 920–1,180 m³/h at up to 815 Pa is sized for exactly such resistance-heavy paths.

My fan got noticeably louder after commissioning — what moved?

Almost always the operating point. If a damper was opened or a filter section was left out, the fan ran out along its curve toward free air — where backward-curved fans get loud. Re-check the system curve against the fan curve and confirm the point still sits right of the pressure peak. If it drifted left of peak, add resistance back or reduce speed; running in the unstable valley causes noise and vibration.
