Product Overview
BC250A-A092D3-01 is an AC centrifugal fan with a 230 Vac 50/60Hz input, delivering 1400/1800 m³/h at up to 615 Pa, 175/230 W, 2600/2850 r/min, 74 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 45–125 FOB Nansha, MOQ 160 pcs, 25–30 days.
- Compact industrial housing (IP54)
- Long-life NSK ball bearings
Selection notes
BC250A-A092D3-01 belongs to the BC250 range: a AC centrifugal fan rated 230 V AC 50/60Hz, 1400/1800 m³/h at up to 615 Pa, 2600/2850 r/min. Speed is set through 3-speed; the datasheet sound pressure is 74 dB(A).
Duty point: 1400/1800 m³/h at 615 Pa. Because speed can be trimmed through 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | BC250A-A092D3-01 |
| Motor Type | AC |
| Airflow | 1400/1800 m³/h |
| Max Static Pressure | 615 Pa |
| Voltage | 230 V AC 50/60Hz |
| Power | 175/230 W |
| Current | 0.8/1.0 A |
| Speed | 2600/2850 r/min |
| Noise | 74 dB(A) |
| Protection Class | IP54 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | Galvanized steel |
| Bearing Type | NSK ball bearing |
| Speed Control | 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 160 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$45–125 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.4)
Special Remarks
[Optional] Impeller material: Galvanized steel plate (powder coating)
Applications
250 mm backward-curved centrifugal fans, 1,080–1,680 m³/h at 590–760 Pa, for air handling units, drying and filtration systems. AC (3-speed), DC and EC versions; EC adds 0-10V/PWM modulation for demand-based operation. Galvanized or PA6+GF25 impeller options, IP54.
Product dataSheets (PDF Download)
View Product dataSheets (PDF) PDF · AC·Centrifugal fan:BC250A-A092D3-01 Product dataSheetsFrequently Asked Questions
Belt-drive or direct-drive centrifugal — why is everything going direct?
Belts eat 2–5% in transmission losses, need periodic tensioning and replacement, and force alignment work at every service. Direct-drive EC — as on this BC250 — removes all of it: the wheel sits on the motor shaft, efficiency is higher, maintenance approaches zero, and speed control comes from the motor electronics instead of a mechanical sheave change.
How do I convert these m³/h and Pa figures to CFM and inches of water?
1 m³/h = 0.589 CFM and 1 Pa = 0.00402 in. w.g. So the BC250’s 1,080–1,680 m³/h at 590–760 Pa reads as roughly 636–989 CFM at 2.4–3.1 in. w.g. Keep source units when comparing against published fan curves — rounding mid-conversion is a classic way to land on the wrong impeller.
What routine maintenance does an EC centrifugal fan need?
Very little by design: bearings are sealed and greased for life, and there is no belt or commutator to wear. The two jobs that matter are cleaning the impeller — dust buildup unbalances the wheel and shows up as vibration before anything else — and re-checking mounting fasteners after the first few hundred hours. A yearly clean-and-vibration pass is a sound default for continuous-duty installs.
