Centrifugal Fan

EC280 Backward-Curved Centrifugal Fan — 1540 m³/h

EC IP54
BC280A-E092D1-01 Centrifugal Fan — 1540 m³/h at 550 Pa
🔍

Product Overview

BC280A-E092D1-01 is an EC centrifugal fan with a 115 Vac input, delivering 1540 m³/h at up to 550 Pa, 125 W, 2300 r/min, 71 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 60–145 FOB Nansha, MOQ 240 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC280A-E092D1-01 belongs to the BC280 range: a EC centrifugal fan rated 115 V AC, 1540 m³/h at up to 550 Pa, 2300 r/min. Speed is set through 0-10V/PWM, Modbus RTU(RS485); the datasheet sound pressure is 71 dB(A).

Duty point: 1540 m³/h at 550 Pa. Because speed can be trimmed through 0-10V/PWM, Modbus RTU(RS485), the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC280A-E092D1-01
Motor Type EC
Airflow 1540 m³/h
Max Static Pressure 550 Pa
Voltage 115 V AC
Power 125 W
Current 1.1 A
Speed 2300 r/min
Noise 71 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material Galvanized steel plate
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, Modbus RTU(RS485)

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 240 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$60–145
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

040080012001600200002004006008001000 Airflow (m³/h) Static pressure (Pa) 1540 m³/h 550 Pa

Dimensions (No.1)

BC280A-E092D1-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: Galvanized steel plate (powder coating)

Applications

280 mm backward-curved EC centrifugal fans: 1,540–2,000 m³/h at 460–715 Pa for AHUs, ERVs and industrial cabinets. 0-10V/PWM plus Modbus RTU over RS485 for BMS integration. Powder-coated galvanized impeller, IP54, -25 °C to +60 °C.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:BC280A-E092D1-01 Product dataSheets

Frequently Asked Questions

What are the benefits of an EC backward-curved centrifugal fan being compatible with both 0-10V/PWM and Modbus RTU (RS485) for speed control?

Equipping an EC backward-curved centrifugal fan with dual compatibility for both analog/PWM signals and digital Modbus RTU (RS485) bridges the gap between simple standalone control and centralized smart automation. ### Key Benefits of Dual-Interface Compatibility #### 1. SKU Consolidation & Supply Chain Efficiency * **Single Fan Model for All Markets:** OEMs and equipment manufacturers don't need to engineer or stock two separate fan variants—one for entry-level analog equipment and another for high-end digital automation. A single fan SKU services simple stand-alone units as well as networked smart buildings or containerized plant factories. * **Lower Inventory Overhead:** Managing a universal motor controller reduces procurement complexity, warehousing costs, and lead times across product lines. #### 2. Simplified Field Commissioning & Local Diagnostics * **Instant On-Site Testing:** Technicians can test and commission the fan using a simple 0-10V handheld potentiometer or PWM generator without bringing a laptop, Modbus master PLC, or network configuration software to the job site. * **Independent Calibration:** Allows quick verification of mechanical balance, rotation direction, and airflow resistance before the central automation bus is fully wired or programmed. #### 3. Redundancy & Fail-Safe Architecture * **Primary Digital Control + Hardwired Safety Override:** Industrial systems can use Modbus RTU for real-time speed adjustment and deep telemetry (power consumption, RPM, internal motor temperature, and fault codes) while reserving the 0-10V or PWM input as a hardwired emergency override (e.g., high-temperature cutoff or fire purge). * **Communication Loss Fallback:** Many EC drives can be configured to automatically fall back to a preset 0-10V signal or fixed PWM duty cycle if RS485 communication drops, ensuring continuous ventilation and preventing critical system shutdowns. #### 4. Flexible Upgrade Path for End Users * **Phased Automation:** Equipment builders can release a base model operating on low-cost analog sensor loops (e.g., direct 0-10V from a CO2 or pressure sensor) and offer an upgrade to full Modbus/IoT network integration as a software or option-card add-on without replacing the fan motor. #### 5. Hybrid Topology Support in Complex Machinery * **Localized Control with Centralized Monitoring:** In large multi-zone systems (such as multi-rack agricultural cleanrooms or fan walls), localized PID loops can use fast-responding 0-10V signals for instant speed adjustments, while the master PLC polls all fans over RS485 for preventive maintenance, energy logging, and diagnostic monitoring.
