EC310 Backward-Curved Centrifugal Fan — 2100 m³/h

EC IP54
BC310A-E092D3-01 Centrifugal Fan — 2100 m³/h at 715 Pa
🔍

Product Overview

BC310A-E092D3-01 is an EC centrifugal fan with a 230 Vac input, delivering 2100 m³/h at up to 715 Pa, 160 W, 1950 r/min, 64 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 65–160 FOB Nansha, MOQ 144 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC310A-E092D3-01 belongs to the BC310 range: a EC centrifugal fan rated 230 V AC, 2100 m³/h at up to 715 Pa, 1950 r/min. Speed is set through 0-10V/PWM, Modbus RTU(RS485); the datasheet sound pressure is 64 dB(A).

Duty point: 2100 m³/h at 715 Pa. Because speed can be trimmed through 0-10V/PWM, Modbus RTU(RS485), the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC310A-E092D3-01
Motor Type EC
Airflow 2100 m³/h
Max Static Pressure 715 Pa
Voltage 230 V AC
Power 160 W
Current 0.7 A
Speed 1950 r/min
Noise 64 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +50 °C
Impeller Material aluminum alloy
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, Modbus RTU(RS485)

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 144 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$65–160
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

01000200030004000500002004006008001000 Airflow (m³/h) Static pressure (Pa) 2100 m³/h 715 Pa

Dimensions (No.1)

BC310A-E092D3-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: aluminum alloy riveting

Applications

The largest SUNXFAN EC centrifugal frame: 1,750–2,500 m³/h at 615–715 Pa with a riveted aluminum impeller. Built for central AHU modules, large FFU arrays and process cooling. 115/230 V AC, 0-10V/PWM and Modbus RTU, IP54.
