Centrifugal Fan

DC140 Single inlet Centrifugal Fan — 430 m³/h

DC IP44
DG140A-D072A6-01 Centrifugal Fan — 430 m³/h at 410 Pa
🔍

Product Overview

DG140A-D072A6-01 is a DC centrifugal fan with a 24 Vdc input, delivering 430 m³/h at up to 410 Pa, 60 W, 1900 r/min, 59 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 30–70 FOB Nansha, MOQ 270 pcs, 25–30 days.

  • Compact industrial housing (IP44)
  • Long-life NSK ball bearings

Selection notes

DG140A-D072A6-01 belongs to the DG140 range: a DC centrifugal fan rated 24 V DC, 430 m³/h at up to 410 Pa, 1900 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 59 dB(A).

Duty point: 430 m³/h at 410 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model DG140A-D072A6-01
Motor Type DC
Airflow 430 m³/h
Max Static Pressure 410 Pa
Voltage 24 V DC
Power 60 W
Current 2.5 A
Speed 1900 r/min
Noise 59 dB(A)
Protection Class IP44
Working Temperature -25 °C ~ +60 °C
Impeller Material PP+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 270 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$30–70
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

01002003004005000100200300400500 Airflow (m³/h) Static pressure (Pa) 430 m³/h 410 Pa

Dimensions (No.3)

DG140A-D072A6-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: Galvanised sheet steel

Applications

Single-inlet 140 mm blowers, 380–460 m³/h at 410–460 Pa. DC (24 V / 310 V) and EC (115/230 V AC) versions share one mounting pattern — change motor technology without touching the chassis. 0-10V/PWM, IP44, galvanized or plastic impeller options.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Centrifugal fan:DG140A-D072A6-01 Product dataSheets

Frequently Asked Questions

24 V or 310 V DC — which version matches my power design?

Match the blower to the bus you already have. This 24 V unit (430 m³/h, 410 Pa, 60 W ≈ 2.5 A) is the natural load for battery-backed sites: forklift-charging rooms, telecom shelters, 24 V cabinet cooling. The 310 V sibling (DG140A-D092A0-01) connects directly across the rectified DC link of inverter-driven appliances, heat pumps and energy-storage cabinets — one conversion stage fewer, one failure mode fewer. Both share the same mounting pattern, so the power architecture can change without redesigning the chassis.

What does clean 0-10V/PWM wiring look like on a DC blower?

Route the control pair as shielded twisted cable, grounded at one end only, and keep it away from the motor leads. Keep the PWM signal inside the frequency range stated in the datasheet, set a minimum-speed floor so the wheel never drops below its stable band, and ramp speed changes over a few seconds instead of stepping — both inrush and acoustic surges come from abrupt steps. Never leave the input floating: an undriven input can drift to an uncommanded speed.

PP+GF or galvanized-steel impeller — which do I order?

Standard is glass-fibre-reinforced polypropylene: immune to humidity, salt air and battery-room acid mist, light on the bearings and on the motor at start-up. Order the galvanized-steel option when the airstream runs persistently near the +60 °C ceiling or carries grease and solvent traces, where polymers age and steel keeps its balance. Both run the same 430 m³/h / 410 Pa duty in this model.
