Product Overview
DG140B-E072D1-01 is an EC centrifugal fan with a 115 Vac input, delivering 460 m³/h at up to 460 Pa, 100 W, 2100 r/min, 64 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 30–70 FOB Nansha, MOQ 270 pcs, 25–30 days.
- Compact industrial housing (IP44)
- Long-life NSK ball bearings
Selection notes
DG140B-E072D1-01 belongs to the DG140 range: a EC centrifugal fan rated 115 V AC, 460 m³/h at up to 460 Pa, 2100 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 64 dB(A).
Duty point: 460 m³/h at 460 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | DG140B-E072D1-01 |
| Motor Type | EC |
| Airflow | 460 m³/h |
| Max Static Pressure | 460 Pa |
| Voltage | 115 V AC |
| Power | 100 W |
| Current | 0.87 A |
| Speed | 2100 r/min |
| Noise | 64 dB(A) |
| Protection Class | IP44 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | PP+GF |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 270 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$30–70 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.2)
Special Remarks
Impeller material options: Galvanised sheet steel
Applications
Single-inlet 140 mm blowers, 380–460 m³/h at 410–460 Pa. DC (24 V / 310 V) and EC (115/230 V AC) versions share one mounting pattern — change motor technology without touching the chassis. 0-10V/PWM, IP44, galvanized or plastic impeller options.
