Centrifugal Fan

EC160 Single inlet Centrifugal Fan — 530 m³/h

EC IP44
DG160A-E072B1-01 Centrifugal Fan — 530 m³/h at 590 Pa
🔍

Product Overview

DG160A-E072B1-01 is an EC centrifugal fan with a 115 Vac input, delivering 530 m³/h at up to 590 Pa, 80 W, 1600 r/min, 59 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 35–100 FOB Nansha, MOQ 254 pcs, 25–30 days.

  • Compact industrial housing (IP44)
  • Long-life NSK ball bearings

Selection notes

DG160A-E072B1-01 belongs to the DG160 range: a EC centrifugal fan rated 115 V AC, 530 m³/h at up to 590 Pa, 1600 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 59 dB(A).

Duty point: 530 m³/h at 590 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model DG160A-E072B1-01
Motor Type EC
Airflow 530 m³/h
Max Static Pressure 590 Pa
Voltage 115 V AC
Power 80 W
Current 0.7 A
Speed 1600 r/min
Noise 59 dB(A)
Protection Class IP44
Working Temperature -25 °C ~ +60 °C
Impeller Material PP+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 254 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$35–100
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

0200400600800100002004006008001000 Airflow (m³/h) Static pressure (Pa) 530 m³/h 590 Pa

Dimensions (No.1)

DG160A-E072B1-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: PP

Applications

530–680 m³/h at 590–680 Pa from a 160 mm single-inlet wheel — pressure above its size class for compact AHU stages, filtration cassettes and appliance air paths. EC with 0-10V/PWM and 3-speed, PP or galvanized impeller, IP44.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:DG160A-E072B1-01 Product dataSheets

Frequently Asked Questions

Why specify an EC motor in a blower this size?

Because these fans spend their life at partial load. An EC motor holds its efficiency across the speed range, while a capacitor or shaded-pole AC motor falls off badly below rated speed — so the 80 W nameplate is what you actually draw at duty, not a laboratory best case. You also get soft start, gentler on the NSK bearings, cooler losses going into the airstream, and native 0-10V/PWM. In a filtration cassette or appliance air path that runs 8,760 hours a year, the energy saving repays the motor premium quickly.

3-speed taps or 0-10V — which control do I need?

Taps suit duty with two or three known states — boost, normal, night — selected by a plain switch, with nothing to program and nothing to fail. 0-10V/PWM earns its cost when the operating point must follow a sensor: CO₂, humidity, temperature or filter pressure drop trims the speed continuously, and any PLC or building controller drives it directly. This blower accepts both, so the design can start simple and gain intelligence later without changing the fan.

Which systems genuinely need 590–680 Pa from a 160 mm wheel?

Systems where one element concentrates the resistance: a deep filter stage, an ERV core, a long or branching small-diameter duct, a condensing-unit casing with coils and bends in series. That is the DG160’s home ground — 530–680 m³/h pushed through real resistance. If your circuit is one clean duct and a grille, this pressure class is over-spec: the DG180 moves 780–960 m³/h at 330–360 Pa and will be quieter per unit of air moved.
