Product Overview
DG160B-E092D3-02 is an EC centrifugal fan with a 230 Vac input, delivering 680 m³/h at up to 680 Pa, 150 W, 2100 r/min, 68 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 35–100 FOB Nansha, MOQ 254 pcs, 25–30 days.
- Compact industrial housing (IP44)
- Long-life NSK ball bearings
Selection notes
DG160B-E092D3-02 belongs to the DG160 range: a EC centrifugal fan rated 230 V AC, 680 m³/h at up to 680 Pa, 2100 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 68 dB(A).
Duty point: 680 m³/h at 680 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | DG160B-E092D3-02 |
| Motor Type | EC |
| Airflow | 680 m³/h |
| Max Static Pressure | 680 Pa |
| Voltage | 230 V AC |
| Power | 150 W |
| Current | 0.65 A |
| Speed | 2100 r/min |
| Noise | 68 dB(A) |
| Protection Class | IP44 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | Galvanised sheet steel |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 254 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$35–100 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.3)
Special Remarks
Impeller material options: Galvanised sheet steel
Applications
530–680 m³/h at 590–680 Pa from a 160 mm single-inlet wheel — pressure above its size class for compact AHU stages, filtration cassettes and appliance air paths. EC with 0-10V/PWM and 3-speed, PP or galvanized impeller, IP44.
