EC180 Single inlet Centrifugal Fan — 960 m³/h

EC IP44
DG180A-E092E1-01 Centrifugal Fan — 960 m³/h at 360 Pa
🔍

Product Overview

DG180A-E092E1-01 is an EC centrifugal fan with a 115 Vac input, delivering 960 m³/h at up to 360 Pa, 175 W, 1320 r/min, 66 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 45–140 FOB Nansha, MOQ 96 pcs, 25–30 days.

  • Compact industrial housing (IP44)
  • Long-life NSK ball bearings

Selection notes

DG180A-E092E1-01 belongs to the DG180 range: a EC centrifugal fan rated 115 V AC, 960 m³/h at up to 360 Pa, 1320 r/min. Speed is set through 0-10V/PWM, 4-speed; the datasheet sound pressure is 66 dB(A).

Duty point: 960 m³/h at 360 Pa. Because speed can be trimmed through 0-10V/PWM, 4-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model DG180A-E092E1-01
Motor Type EC
Airflow 960 m³/h
Max Static Pressure 360 Pa
Voltage 115 V AC
Power 175 W
Current 1.5 A
Speed 1320 r/min
Noise 66 dB(A)
Protection Class IP44
Working Temperature -25 °C ~ +60 °C
Impeller Material PP+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 4-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 96 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$45–140
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

020040060080010000100200300400500 Airflow (m³/h) Static pressure (Pa) 960 m³/h 360 Pa

Dimensions (No.1)

DG180A-E092E1-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material options: PP

Applications

An airflow-first single-inlet blower: 780–960 m³/h at 330–360 Pa, tuned for short-duct and grille duty in condensing units, appliance exhaust and cabinet exchange. EC with 0-10V/PWM and 4-speed, PP impeller, IP44.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:DG180A-E092E1-01 Product dataSheets

Frequently Asked Questions

When is a 330–360 Pa, high-airflow blower the right choice?

When the resistance is short and honest: condensing-unit discharge, appliance exhaust up a short stack, cabinet air exchange through a grille and maybe one bend. 780–960 m³/h at 330–360 Pa moves serious volume through such paths without paying the noise and power premium of a high-pressure wheel fighting an open system. The mistake to avoid is the reverse: a 700 Pa-class blower on a 150 Pa system rides far off its design point, wastes energy and sounds harsh.

4-speed taps or 0-10V/PWM — how do I choose?

The 4-speed taps serve uncontrolled installs: a technician sets one point with a jumper or switch — kitchen boost, condenser duty, appliance exhaust — and the fixed steps guarantee repeatable airflow and noise. 0-10V/PWM is for when a controller or BMS will trim speed against a sensor. On fixed duty, land the tap on your actual system curve rather than defaulting to the fastest: each step down buys several dB(A) and a cubic saving in power.

What does the PP impeller contribute here?

Glass-fibre-filled polypropylene keeps wheel mass low: gentle bearing loads over years of continuous running and little start inertia for the EC motor. It is intrinsically corrosion-proof — salt air, humidity and cleaning-agent traces that pit coated steel leave it untouched, which is why appliance and marine-air-conditioning duty favours it. The honest trade is temperature: respect the −25 ~ +60 °C envelope; for airstreams that live near that ceiling, specify a steel-wheel blower instead.
