Product Overview
The DG180B-E092D3-01 is a high-efficiency EC single-inlet centrifugal fan rated for 780 m³/h airflow and up to 330 Pa static pressure. Its EC motor delivers precise, energy-saving speed control (0-10V/PWM, 3-speed). The backward-curved impeller maintains high efficiency against duct system resistance.
- Compact industrial housing (IP44)
- Long-life NSK ball bearings
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | DG180B-E092D3-01 |
| Motor Type | EC |
| Airflow | 780 m³/h |
| Max Static Pressure | 330 Pa |
| Voltage | 230 V AC |
| Power | 120 W |
| Current | |
| Speed | 1350 r/min |
| Noise | 67 dB(A) |
| Protection Class | IP44 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | galvanised sheet steel |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 3-speed |
Applications
For high-capacity ventilation in North American commercial kitchen exhaust systems, the DG180A-E092E1-01 (EC, 115 V AC, 960 m³/h, 175 W) is suitable for rapid removal of heat, smoke, and grease-laden air while maintaining energy-efficient EC motor operation. For comparable European kitchen installations requiring 230 V AC supply, the DG180A-E092E3-01 (EC, 230 V AC, 960 m³/h, 175 W) is suitable for the same high-airflow duty with lower current draw and simplified wiring. For medium-sized North American server room or electrical cabinet cooling where continuous, reliable airflow is critical, the DG180B-E092D1-01 (EC, 115 V AC, 780 m³/h, 120 W) is suitable for maintaining safe operating temperatures with reduced power consumption. For European industrial control panels or telecom racks operating on 230 V AC, the DG180B-E092D3-01 (EC, 230 V AC, 780 m³/h, 120 W) is suitable for dependable thermal management with quiet, efficient EC motor performance.
Ordering Information
| MOQ (Min. Order Qty) | 96 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.3)
Special Remarks
Impeller material options: galvanized sheet
