Product Overview
SF146D-E092A1-01 is an EC centrifugal fan with a 115 Vac input, delivering 860 m³/h at up to 515 Pa, 120 W, 1650 r/min, 60±1 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 50–150 FOB Nansha, MOQ 120 pcs, 25–30 days.
- Compact industrial housing (IP42)
- Long-life NSK ball bearings
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | SF146D-E092A1-01 |
| Motor Type | EC |
| Airflow | 860 m³/h |
| Max Static Pressure | 515 Pa |
| Voltage | 115 V AC |
| Power | 120 W |
| Current | 1 A |
| Speed | 1650 r/min |
| Noise | 60±1 dB(A) |
| Protection Class | IP42 |
| Working Temperature | -25 °C ~ +50 °C |
| Impeller Material | PA6+GF25% |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 0-5V, 0-6.5V, 3-speed, 4-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 120 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$50–150 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions
Special Remarks
[Optional] Housing and impeller material: PP
Applications
146 mm dual-inlet blowers balanced between pressure and flow: 860–1,160 m³/h at 515–585 Pa for slim AHU stages, range hoods, air curtains and display cases. 48 V DC and 115/230 V EC builds, 0-10V/PWM, IP42/54.
