EC300 Axial Fan — 2200 m³/h

EC IP54
AF300A-E092A3-01 Axial Fan — 2200 m³/h at 180 Pa
🔍

Product Overview

AF300A-E092A3-01 is an EC axial fan with a 230 Vac input, delivering 2200 m³/h at up to 180 Pa, 165 W, 2100 r/min, 66 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 22–75 FOB Nansha, MOQ 160 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

AF300A-E092A3-01 belongs to the AF Axial-Fan Guard range: a EC centrifugal fan rated 230 V AC, 2200 m³/h at up to 180 Pa, 2100 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 66 dB(A).

Duty point: 2200 m³/h at 180 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AF300A-E092A3-01
Motor Type EC
Airflow 2200 m³/h
Max Static Pressure 180 Pa
Voltage 230 V AC
Power 165 W
Current 0.72 A
Speed 2100 r/min
Noise 66 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA66+GF
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 160 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$22–75
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

01000200030004000500004080120160200 Airflow (m³/h) Static pressure (Pa) 2200 m³/h 180 Pa

Dimensions (No.1)

AF300A-E092A3-01 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Inlet Guard material options: Powder-coated Wire Guard

Applications

Guarded axial fans for free-air blowing and low-pressure ducted duty — condensers, dry coolers, evaporators and outdoor machine compartments. Below ~300 Pa axial geometry moves the most air per watt; this series covers 1,750–10,000 m³/h at up to 300 Pa. AC (230 V / 380 V 3-ph) and EC builds, IP54, powder-coated wire guard fitted.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Axial fan:AF300A-E092A3-01 Product dataSheets

Frequently Asked Questions

Why do condensers, dry coolers and evaporators use axial fans instead of centrifugal?

Coil duty is high volume at low resistance — air crossing a finned coil typically needs only 100–300 Pa. In that band an axial fan moves more air per watt and per dollar than any centrifugal. The AF series is built for exactly this window: 1,750–10,000 m³/h at up to 300 Pa, with the guard already included in the performance data.

Does the finger guard cost me airflow?

A well-designed rounded-wire guard costs typically under 5% of free-airflow, and our published curves are measured with the guard fitted — what you read is what you get. Never spec a bare fan and add a guard later: the operating point shifts and noise can rise. The guard also keeps leaves, cables and fingers out of the blade plane, a compliance requirement for accessible outdoor units.

How do I split airflow across several fans on one condenser?

Size by coil face velocity first — 2.5–3.5 m/s is the usual condenser window — then divide the total volume among the fan positions. In parallel, airflows add nearly linearly, but note that two identical fans together add about 3 dB(A) and four add about 6 dB(A), which matters near night-time noise limits.
