Product Overview
AF500D-A106C3-01 is an AC axial fan with a 3–380 Vac input, delivering 7050 m³/h at up to 180 Pa, 410 W, 1380 r/min, 73 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 22–75 FOB Nansha, MOQ 360 pcs, 25–30 days.
- Compact industrial housing (IP54)
- Long-life ball bearings
Selection notes
AF500D-A106C3-01 belongs to the AF Axial-Fan Guard range: a AC centrifugal fan rated 3-380 V AC, 7050 m³/h at up to 180 Pa, 1380 r/min. Speed is set through —; the datasheet sound pressure is 73 dB(A).
Duty point: 7050 m³/h at 180 Pa. Because speed can be trimmed through —, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Axial Fan |
|---|---|
| Model | AF500D-A106C3-01 |
| Motor Type | AC |
| Airflow | 7050 m³/h |
| Max Static Pressure | 180 Pa |
| Voltage | 3-380 V AC |
| Power | 410 W |
| Current | 0.75 A |
| Speed | 1380 r/min |
| Noise | 73 dB(A) |
| Protection Class | IP54 |
| Working Temperature | -25 °C ~ +70 °C |
| Impeller Material | Galvanized steel |
| Bearing Type | ball bearing |
| Speed Control |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 360 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$22–75 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.4)
Special Remarks
Inlet Guard material options: Powder-coated Wire Guard
Applications
Guarded axial fans for free-air blowing and low-pressure ducted duty — condensers, dry coolers, evaporators and outdoor machine compartments. Below ~300 Pa axial geometry moves the most air per watt; this series covers 1,750–10,000 m³/h at up to 300 Pa. AC (230 V / 380 V 3-ph) and EC builds, IP54, powder-coated wire guard fitted.
