Axial Fan

AC300 Axial Fan — 1750 m³/h

AC IP54
AF300D-A092A3-01 Axial Fan — 1750 m³/h at 180 Pa
🔍

Product Overview

AF300D-A092A3-01 is an AC axial fan with a 3–380 Vac input, delivering 1750 m³/h at up to 180 Pa, 75 W, 1350 r/min, 55 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 22–75 FOB Nansha, MOQ 360 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life ball bearings

Selection notes

AF300D-A092A3-01 belongs to the AF Axial-Fan Guard range: a AC centrifugal fan rated 3-380 V AC, 1750 m³/h at up to 180 Pa, 1350 r/min. Speed is set through —; the datasheet sound pressure is 55 dB(A).

Duty point: 1750 m³/h at 180 Pa. Because speed can be trimmed through —, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AF300D-A092A3-01
Motor Type AC
Airflow 1750 m³/h
Max Static Pressure 180 Pa
Voltage 3-380 V AC
Power 75 W
Current 0.2 A
Speed 1350 r/min
Noise 55 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +70 °C
Impeller Material Galvanized steel
Bearing Type ball bearing
Speed Control

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 360 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$22–75
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

040080012001600200004080120160200 Airflow (m³/h) Static pressure (Pa) 1750 m³/h 180 Pa

Dimensions (No.2)

AF300D-A092A3-01 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Inlet Guard material options: Powder-coated Wire Guard

Applications

Guarded axial fans for free-air blowing and low-pressure ducted duty — condensers, dry coolers, evaporators and outdoor machine compartments. Below ~300 Pa axial geometry moves the most air per watt; this series covers 1,750–10,000 m³/h at up to 300 Pa. AC (230 V / 380 V 3-ph) and EC builds, IP54, powder-coated wire guard fitted.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · AC·Axial fan:AF300D-A092A3-01 Product dataSheets
