DC305 Axial Fan — 4000 m³/h

DC IP68
AG305A-D092BA-Y1 Axial Fan — 4000 m³/h at 750 Pa
🔍

Product Overview

AG305A-D092BA-Y1 is a DC axial fan with a 480–650 Vdc input, delivering 4000 m³/h at up to 750 Pa, 1200 W. Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 150–1200 FOB Nansha, MOQ 165 pcs, 25–30 days.

  • Compact industrial housing (IP68)
  • Long-life ball bearings

Selection notes

AG305A-D092BA-Y1 belongs to the 800VDC Axial-Fan range: a DC centrifugal fan rated 480-650 V DC, 4000 m³/h at up to 750 Pa, . Speed is set through CAN 2.0 / CAN FD; the datasheet sound pressure is .

Duty point: 4000 m³/h at 750 Pa. Because speed can be trimmed through CAN 2.0 / CAN FD, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AG305A-D092BA-Y1
Motor Type DC
Airflow 4000 m³/h
Max Static Pressure 750 Pa
Voltage 480-650 V DC
Power 1200 W
Current 2 A
Speed
Noise
Protection Class IP68
Working Temperature -40 °C ~ +85 °C
Impeller Material PA66+GF
Bearing Type ball bearing
Speed Control CAN 2.0 / CAN FD

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 165 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$150–1200
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

01000200030004000500002004006008001000 Airflow (m³/h) Static pressure (Pa) 4000 m³/h 750 Pa

Dimensions (No.2)

AG305A-D092BA-Y1 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Bus input voltage: 480-650 VDC; maximum input frequency: 1000 Hz; sensorless sinusoidal FOC

Applications

High-voltage DC axial fans that connect straight to the DC bus of solar, storage and battery-test systems — 420–800 V wide input, IP68. 1,950–9,000 m³/h at up to 1,550 Pa for battery-room ventilation and power-electronics cooling, with no inverter stage. 0-10V/PWM control; CAN 2.0/CAN FD telemetry available.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Axial fan:AG305A-D092BA-Y1 Product dataSheets
