DC400 Axial Fan — 9000 m³/h

DC IP68
AG400A-D092BA-02 Axial Fan — 9000 m³/h at 850 Pa
🔍

Product Overview

AG400A-D092BA-02 is a DC axial fan with a 420–750 Vdc input, delivering 9000 m³/h at up to 850 Pa, 1500 W, 3500 r/min, 75 dB(A). Used in condensers, dry coolers, cooling towers and switchgear cabinets. USD 150–1200 FOB Nansha, MOQ 144 pcs, 25–30 days.

  • Compact industrial housing (IP68)
  • Long-life ball bearings

Selection notes

AG400A-D092BA-02 belongs to the 800VDC Axial-Fan range: a DC centrifugal fan rated 420-750 V DC, 9000 m³/h at up to 850 Pa, 3500 r/min. Speed is set through CAN 2.0 / CAN FD; the datasheet sound pressure is 75 dB(A).

Duty point: 9000 m³/h at 850 Pa. Because speed can be trimmed through CAN 2.0 / CAN FD, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Axial Fan
Model AG400A-D092BA-02
Motor Type DC
Airflow 9000 m³/h
Max Static Pressure 850 Pa
Voltage 420-750 V DC
Power 1500 W
Current 2–3.6 A
Speed 3500 r/min
Noise 75 dB(A)
Protection Class IP68
Working Temperature -40 °C ~ +65 °C
Impeller Material PA6+GF30
Bearing Type ball bearing
Speed Control CAN 2.0 / CAN FD

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 144 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$150–1200
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

020004000600080001000002004006008001000 Airflow (m³/h) Static pressure (Pa) 9000 m³/h 850 Pa

Dimensions (No.3)

AG400A-D092BA-02 Axial Fan — outline drawing, dimensions in mm

Special Remarks

Bus input voltage: 420-750 VDC; sensorless sinusoidal FOC; Over-temperature protection: 110±5℃

Applications

High-voltage DC axial fans that connect straight to the DC bus of solar, storage and battery-test systems — 420–800 V wide input, IP68. 1,950–9,000 m³/h at up to 1,550 Pa for battery-room ventilation and power-electronics cooling, with no inverter stage. 0-10V/PWM control; CAN 2.0/CAN FD telemetry available.
