DC190 Backward-Curved Centrifugal Fan — 660 m³/h

DC IP54
BC190B-D072A6-01 Centrifugal Fan — 660 m³/h at 500 Pa
🔍

Product Overview

BC190B-D072A6-01 is a DC centrifugal fan with a 24 Vdc input, delivering 660 m³/h at up to 500 Pa, 70 W, 3150 r/min, 65±2 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 35–80 FOB Nansha, MOQ 160 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC190B-D072A6-01 belongs to the BC190 range: a DC centrifugal fan rated 24 V DC, 660 m³/h at up to 500 Pa, 3150 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 65±2 dB(A).

Duty point: 660 m³/h at 500 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC190B-D072A6-01
Motor Type DC
Airflow 660 m³/h
Max Static Pressure 500 Pa
Voltage 24 V DC
Power 70 W
Current 3.0±7% A
Speed 3150 r/min
Noise 65±2 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 160 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$35–80
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

020040060080010000100200300400500 Airflow (m³/h) Static pressure (Pa) 660 m³/h 500 Pa

Dimensions (No.4)

BC190B-D072A6-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

The 190 mm backward-curved workhorse: 530–780 m³/h at 500–770 Pa for telecom shelters, battery cabinets and compact AHUs. EC (115/230 V AC) and DC (24/48 V) builds, all with 0-10V/PWM. IP54, PA6+GF25 impeller, -25 °C to +60 °C.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Centrifugal fan:BC190B-D072A6-01 Product dataSheets
