Product Overview
BC190B-E072A1-01 is an EC centrifugal fan with a 115 Vac input, delivering 530 m³/h at up to 590 Pa, 60 W, 2600 r/min, 62 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 35–80 FOB Nansha, MOQ 432 pcs, 25–30 days.
- Compact industrial housing (IP54)
- Long-life NSK ball bearings
Selection notes
BC190B-E072A1-01 belongs to the BC190 range: a EC centrifugal fan rated 115 V AC, 530 m³/h at up to 590 Pa, 2600 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 62 dB(A).
Duty point: 530 m³/h at 590 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | BC190B-E072A1-01 |
| Motor Type | EC |
| Airflow | 530 m³/h |
| Max Static Pressure | 590 Pa |
| Voltage | 115 V AC |
| Power | 60 W |
| Current | 0.52 A |
| Speed | 2600 r/min |
| Noise | 62 dB(A) |
| Protection Class | IP54 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | PA6+GF25% |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 432 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$35–80 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions (No.1)
Special Remarks
[Optional] Impeller material: PA Or Galvanized steel plate (powder coating)
Applications
The 190 mm backward-curved workhorse: 530–780 m³/h at 500–770 Pa for telecom shelters, battery cabinets and compact AHUs. EC (115/230 V AC) and DC (24/48 V) builds, all with 0-10V/PWM. IP54, PA6+GF25 impeller, -25 °C to +60 °C.
