DC190 Backward-Curved Centrifugal Fan — 620 m³/h

DC IP54
BC190A-D072A8-01 Centrifugal Fan — 620 m³/h at 500 Pa
🔍

Product Overview

BC190A-D072A8-01 is a DC centrifugal fan with a 48 Vdc input, delivering 620 m³/h at up to 500 Pa, 58 W, 3000 r/min, 63±2 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 35–80 FOB Nansha, MOQ 160 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC190A-D072A8-01 belongs to the BC190 range: a DC centrifugal fan rated 48 V DC, 620 m³/h at up to 500 Pa, 3000 r/min. Speed is set through 0-10V/PWM; the datasheet sound pressure is 63±2 dB(A).

Duty point: 620 m³/h at 500 Pa. Because speed can be trimmed through 0-10V/PWM, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC190A-D072A8-01
Motor Type DC
Airflow 620 m³/h
Max Static Pressure 500 Pa
Voltage 48 V DC
Power 58 W
Current 1.2±7% A
Speed 3000 r/min
Noise 63±2 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 160 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$35–80
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

020040060080010000100200300400500 Airflow (m³/h) Static pressure (Pa) 620 m³/h 500 Pa

Dimensions (No.3)

BC190A-D072A8-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

The 190 mm backward-curved workhorse: 530–780 m³/h at 500–770 Pa for telecom shelters, battery cabinets and compact AHUs. EC (115/230 V AC) and DC (24/48 V) builds, all with 0-10V/PWM. IP54, PA6+GF25 impeller, -25 °C to +60 °C.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · DC·Centrifugal fan:BC190A-D072A8-01 Product dataSheets

Frequently Asked Questions

How much energy does slowing an EC fan actually save?

Fan laws: airflow scales linearly with speed, pressure with its square, and power with its cube. Drop speed 20% and power falls to about half; 30% saves roughly two-thirds. That cube law is why EC modulation pays back quickly on any fan running long hours at part load, while an AC fan on step control can only sit on a fixed tap.

24 V or 48 V DC — how do I choose between the BC190 builds?

Follow the bus you already have: 24 V is the solar, off-grid and vehicle standard; 48 V is telecom and IT. At the same power, doubling voltage halves current, so 48 V wiring loses four times less energy as heat (I²R) and can run thinner conductors. If you are designing the power system rather than matching it, 48 V is usually the better physics.

Is this fan rated for continuous 24/7 duty in electronics cabinets?

Yes — that is its core job. IP54 sealing, ball bearings and a −25 °C to +60 °C window cover shelter and cabinet environments, and the EC motor’s cool-running efficiency means less self-heating in a sealed enclosure. Keep the inlet clear and dust the impeller occasionally; dust imbalance is the main real-world source of vibration.
