AC225 3-Speed Backward-Curved Centrifugal Fan — 1100 m³/h

AC IP54
BC225A-A092C2-01 Centrifugal Fan — 1100/890/750 m³/h at 500 Pa
🔍

Product Overview

BC225A-A092C2-01 is an AC centrifugal fan with a 230 Vac 50/60Hz input, delivering 1100/890/750 m³/h at up to 500 Pa, 120/95/87 W, 2515/2234/1930 r/min, 69 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 40–110 FOB Nansha, MOQ 160 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC225A-A092C2-01 belongs to the BC225 range: a AC centrifugal fan rated 230 V AC 50/60Hz, 1100/890/750 m³/h at up to 500 Pa, 2515/2234/1930 r/min. Speed is set through 3-speed; the datasheet sound pressure is 69 dB(A).

Duty point: 1100/890/750 m³/h at 500 Pa. Because speed can be trimmed through 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC225A-A092C2-01
Motor Type AC
Airflow 1100/890/750 m³/h
Max Static Pressure 500 Pa
Voltage 230 V AC 50/60Hz
Power 120/95/87 W
Current 0.52/0.43/0.4 A
Speed 2515/2234/1930 r/min
Noise 69 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 160 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$40–110
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

04008001200160020000100200300400500 Airflow (m³/h) Static pressure (Pa) 1100 m³/h 500 Pa

Dimensions (No.5)

BC225A-A092C2-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

Impeller material: PA6+GF25%

Applications

Nine models on one 225 mm platform — AC, DC (24/48/310 V) and EC — sharing 1,020–1,420 m³/h at up to 690 Pa. Built as a drop-in platform for AHU, dehumidifier and heat-pump OEMs: one mechanical cut-out, any electrical scheme. IP54, ball bearings, continuous duty.
