EC225 Backward-Curved Centrifugal Fan — 1200 m³/h

EC IP54
BC225A-E072B3-01 Centrifugal Fan — 1200 m³/h at 550 Pa
🔍

Product Overview

BC225A-E072B3-01 is an EC centrifugal fan with a 230 Vac input, delivering 1200 m³/h at up to 550 Pa, 90 W, 2700 r/min, 68 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 40–110 FOB Nansha, MOQ 160 pcs, 25–30 days.

  • Compact industrial housing (IP54)
  • Long-life NSK ball bearings

Selection notes

BC225A-E072B3-01 belongs to the BC225 range: a EC centrifugal fan rated 230 V AC, 1200 m³/h at up to 550 Pa, 2700 r/min. Speed is set through 0-10V/PWM, 3-speed; the datasheet sound pressure is 68 dB(A).

Duty point: 1200 m³/h at 550 Pa. Because speed can be trimmed through 0-10V/PWM, 3-speed, the same unit can be re-set on site if the measured system resistance differs from the design value. For the destination market the grid is typically 110–240 V, 50/60 Hz, with CE, UL/ETL or CCC depending on destination as the compliance framework.

Technical Specifications

Category Centrifugal Fan
Model BC225A-E072B3-01
Motor Type EC
Airflow 1200 m³/h
Max Static Pressure 550 Pa
Voltage 230 V AC
Power 90 W
Current 0.39 A
Speed 2700 r/min
Noise 68 dB(A)
Protection Class IP54
Working Temperature -25 °C ~ +60 °C
Impeller Material PA6+GF25%
Bearing Type NSK ball bearing
Speed Control 0-10V/PWM, 3-speed

Data updated 2026-10

Ordering Information

MOQ (Min. Order Qty) 160 PCS
FOB Price FOB Nansha Guangzhou
Reference price US$40–110
Lead Time 25-30 days
Sample Sample available
Payment Terms TT
Shipping Port Nansha Guangzhou OR Yantian Shenzhen

Performance Curves

040080012001600200002004006008001000 Airflow (m³/h) Static pressure (Pa) 1200 m³/h 550 Pa

Dimensions (No.3)

BC225A-E072B3-01 Centrifugal Fan — outline drawing, dimensions in mm

Special Remarks

[Optional] Impeller material: PA Or Galvanized steel plate (powder coating)

Applications

Nine models on one 225 mm platform — AC, DC (24/48/310 V) and EC — sharing 1,020–1,420 m³/h at up to 690 Pa. Built as a drop-in platform for AHU, dehumidifier and heat-pump OEMs: one mechanical cut-out, any electrical scheme. IP54, ball bearings, continuous duty.

Product dataSheets (PDF Download)

View Product dataSheets (PDF) PDF · EC·Centrifugal fan:BC225A-E072B3-01 Product dataSheets
