Product Overview
CF100A-E072A3-01 is an EC fan unit with a 230 Vac input, delivering 320 m³/h at up to 905 Pa, 85 W, 3300 r/min, 58 dB(A). Used in AHUs, ducted ventilation and ERV/HRV units. USD 35–170 FOB Nansha, MOQ 384 pcs, 25–30 days.
- Model: CF100A-E072A3-01
- Motor type: EC
- Protection class: IP54
- Noise level: 58 dB(A)
Technical Specifications
| Category | Fan Units |
|---|---|
| Model | CF100A-E072A3-01 |
| Motor Type | EC |
| Airflow | 320 m³/h |
| Max Static Pressure | 905 Pa |
| Voltage | 230 VAC |
| Power | 85 W |
| Current | 0.37 A |
| Speed | 3300 r/min |
| Noise | 58 dB(A) |
| Protection Class | IP54 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | PA+GF |
| Bearing Type | Ball Bearing |
| Speed Control | 0-10V/PWM, 0-5V, 0-6.5V, 3-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 384 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$35–170 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions
Special Remarks
Optional wireless speed controller; Wi-Fi connectivity-For more technical information on EC Duct Fans, please contact our sales team.
Applications
EC inline duct fans (100–315 mm spigot) that clamp into round ducting: 320–1,750 m³/h at up to 1,010 Pa. Backward-curved EC wheels develop real static pressure where cheap axial duct fans stall. 120/230 V versions, 0-10V/PWM, IP54, 58–66 dB(A).
Product dataSheets (PDF Download)
View Product dataSheets (PDF) PDF · EC·Fan unit:CF100A-E072A3-01 Product dataSheetsFrequently Asked Questions
We are currently using an AC Duct Fan and do not want to change the existing installation dimensions. Can we replace it with your company's EC Duct Fan?
Yes, our company's EC Duct Fan installation dimensions are compatible with those of AC Duct Fans. This compatibility means that when replacing or upgrading from an AC Duct Fan to an EC Duct Fan, the existing mounting holes, duct connections, and overall installation clearances can typically be reused without modification. As a result, the swap is straightforward and does not require additional adapters or rework of the ductwork or mounting structure.
