Product Overview
SF160D-E092A3-01 is an EC centrifugal fan with a 230 Vac input, delivering 1200 m³/h at up to 680 Pa, 165 W, 1400 r/min, 52±2 dB(A). Used in AHUs, fan coils, range hoods, air purifiers and ERV units. USD 75–175 FOB Nansha, MOQ 96 pcs, 25–30 days.
- Compact industrial housing (IP44)
- Long-life NSK ball bearings
Technical Specifications
| Category | Centrifugal Fan |
|---|---|
| Model | SF160D-E092A3-01 |
| Motor Type | EC |
| Airflow | 1200 m³/h |
| Max Static Pressure | 680 Pa |
| Voltage | 230 V AC |
| Power | 165 W |
| Current | 0.72 A |
| Speed | 1400 r/min |
| Noise | 52±2 dB(A) |
| Protection Class | IP44 |
| Working Temperature | -25 °C ~ +60 °C |
| Impeller Material | PA6+GF25% |
| Bearing Type | NSK ball bearing |
| Speed Control | 0-10V/PWM, 4-speed |
Data updated 2026-10
Ordering Information
| MOQ (Min. Order Qty) | 96 PCS |
|---|---|
| FOB Price | FOB Nansha Guangzhou |
| Reference price | US$75–175 |
| Lead Time | 25-30 days |
| Sample | Sample available |
| Payment Terms | TT |
| Shipping Port | Nansha Guangzhou OR Yantian Shenzhen |
Other Models in This Series
Performance Curves
Dimensions
Special Remarks
Airflow at 200 Pa: 940 m³/h
Applications
160 mm double-inlet (DIDW) EC blowers, 1,200–1,700 m³/h at up to 705 Pa, running at just 52–62 dB(A) — the quiet blower for range hoods, air purifiers, air curtains and compact AHUs. 115/230 V AC, 0-10V/PWM, IP44.
